if FRedaction then
    Control := NewListEdit(FParent, FStyle, l, LgIList, SmIList, StIList,
                           _OnLineChange, _OnBeforeLineChange)
  else
    Control := NewListView(FParent, FStyle, l, LgIList, SmIList, StIList);

Add(MainForm,314817,336,154)
{
 Width=445
 Height=261
 Caption="Пример использования MST_UseEditCtrl"
 Position=1
 link(onCreate,10041622:doEnum,[])
}
Add(MST_UseEditCtrl,3498945,329,252)
{
 MSTControl="MtS_tbl"
 PColor(onCellSize,8421440)
 PColor(onEscCell,32768)
 link(onCellSize,13620734:doValue,[(375,258)(375,223)])
 link(onEnterCell,87120:doEvent1,[])
 link(onEscCell,9235417:doEvent,[(374,272)(374,293)])
}
Add(StrList,15034837,399,112)
{
 Strings=#15:sdfsdf;aaaaa;;0|15:fzsdfzs;bbbb;;3|14:sdfszz;cccc;;2|15:sdfszz;ddddd;;0|15:sdfszz;eeeee;;1|15:sdfszz;fffff;;3|15:fzsdfzs;gggg;;2|14:sdfszz;hhhh;;0|16:fzsdfzs;iiiii;;3|16:sdfszz;jjjjjj;;1|
}
Add(MT_String,922736,469,154)
{
 link(onResult,2904434:doRowAction,[])
}
Add(ArrayEnum,10041622,413,168)
{
 link(onItem,922736:doMTString,[])
 link(Array,15034837:Array,[])
}
Add(MST_RowAction,2904434,525,154)
{
 MSTControl="MtS_tbl"
}
Add(MT_MultiData,2622840,413,259)
{
 Point(Data)
 link(onData1,9450650:doLeft,[])
 link(onData2,9450650:doTop,[])
 link(Data,13620734:Value,[])
}
Add(Hub,15922927,476,273)
{
 link(onEvent1,9450650:doSetFocus,[])
 link(onEvent2,9450650:doBringToFront,[])
}
Add(Hub,87120,385,259)
{
 link(onEvent1,2622840:doSeparateMT,[])
 link(onEvent2,15922927:doEvent1,[(407,272)(407,279)])
}
Add(DatePicker,9450650,525,252)
{
 Left=30
 Top=205
 Width=90
 Font=[MS Sans Serif,6,0,0,1]
 Point(doLeft)
 Point(doTop)
 Point(doSetFocus)
 Point(doBringToFront)
 Point(DateTime)
 Point(doSendToBack)
 link(onChange,10029744:doConvert,[(571,258)(571,303)(513,303)(513,321)])
}
Add(DateConvertor,10029744,525,315)
{
 Mode=9
 Format="dd-MM-yyyy"
 Point(Data)
 link(onResult,3498945:doSetData,[(571,321)(571,359)(317,359)(317,258)])
 link(Data,9450650:DateTime,[])
}
Add(MTStrTbl,9842821,336,112)
{
 Left=25
 Top=20
 Width=360
 Height=170
 Font=[MS Sans Serif,12,0,0,1]
 Name="MtS_tbl"
 Columns=#1:1|1:2|1:3|
 ColumnWidth=90
}
Add(MT_Memory,13620734,413,217)
{
}
Add(Debug,9235417,392,287)
{
 link(onEvent,9450650:doSendToBack,[])
}

unit hiMST_UseEditCtrl;

interface

uses Windows, Messages, Kol, Share, Debug, hiMTStrTbl;

const
  HDN_FIRST        = -300;           { Header }
  HDN_ITEMCHANGEDA = HDN_FIRST-1;
  HDN_ITEMCHANGEDW = HDN_FIRST - 21;

type
  tagNMHEADERA = packed record
    Hdr: TNMHdr;
    Item: Integer;
    Button: Integer;
    PItem: PHDItemA;
  end;
  HD_NOTIFY = tagNMHEADERA;


type
  THIMST_UseEditCtrl = class(TDebug)
   private
     sControl: PControl;
     NewLine: integer;
     FMSTControl: IMSTControl;
     OldMessage: TOnMessage;
	 redaction: boolean;//test

     procedure SetMSTControl(Value: IMSTControl);
     procedure snewcuridx(value:integer);
     function gnewcuridx: integer;
     function fredaction: boolean;
     function fctl3d: boolean;
   public

     _prop_KeyCellEnter: byte;
     _prop_DblClick: boolean;
     _data_Row: THI_Event;
     _data_Col: THI_Event;
     _event_onEscCell: THI_Event;
     _event_onEnterCell: THI_Event;
     _event_onCellSize: THI_Event;
     _event_onClientRect: THI_Event;

     property _prop_MSTControl: IMSTControl read FMSTControl write SetMSTControl;
     property NewCurIdx:integer read gnewcuridx write snewcuridx;

     procedure _work_doSetData(var _Data: TData; Index: word);
     procedure _work_doClientRect(var _Data: TData; Index: word);
     procedure _var_Index(var _Data: TData; Index: word);
     procedure _var_Cell(var _Data: TData; Index: word);
     procedure _var_SubItem(var _Data: TData; Index: word);
     procedure _var_Matrix(var _Data: TData; Index: word);
   protected
     function _OnMessage(var Msg: TMsg; var Rslt: Integer): Boolean;
  end;

implementation


//------------------------------------------------------------------------------
//
function THIMST_UseEditCtrl._OnMessage;
type
  TMouseDownPt = packed record
    X: Word;
    Y: Word;
  end;
var
  R, ARect: TRect;
  Pt: TMouseDownPt;
  HTI: TLVHitTestInfo;
  Data: TData;
  mt: PMT;
  l: TListViewOptions;

  procedure InitOnEvent;
  var
    b: integer;
  begin
    if FRedaction then exit;
    redaction := true;//test
    R := sControl.LVSubItemRect(NewLine, NewCurIdx);
    if NewCurIdx = 0 then
    begin
      ARect := sControl.LVItemRect(NewLine, lvipLabel);
      R.Left := ARect.Left;
      R.Right := ARect.Right;
    end;
    if fctl3d then
      b := 2
    else
      b := 1;
    l := sControl.LVOptions;

    dtInteger(Data, R.Left + sControl.Left + b);
    mt := mt_make(Data);
    mt_int(mt, R.Top + sControl.Top + b);
    mt_int(mt, R.Right - R.Left - 1);
    mt_int(mt, R.Bottom - R.Top - 1);
    _hi_OnEvent_(_event_onCellSize, Data);
    mt_free(mt);
  end;

  procedure EscCell;
  begin
    if not redaction then exit;//test
    redaction := false;//test
    R := sControl.LVItemRect(NewLine, lvipBounds);
    ARect := sControl.LVItemRect(NewLine, lvipLabel);
    R.Left := ARect.Left;
    InvalidateRect(sControl.Handle, @R, false);
    if not FRedaction then
      _hi_OnEvent(_event_onEscCell, sControl.LVItems[NewLine, NewCurIdx]);
  end;

begin
  Result := false;
  l:= sControl.LVOptions;
  case Msg.message of
    WM_NOTIFY:
      if (HD_NOTIFY(Pointer(Msg.LParam)^).Hdr.code = HDN_ITEMCHANGEDA) or
         (HD_NOTIFY(Pointer(Msg.LParam)^).Hdr.code = HDN_ITEMCHANGEDW) then
        InitOnEvent;
    WM_RBUTTONDOWN, WM_LBUTTONDOWN:
    begin
      Pt:= TMouseDownPt(Msg.lParam);
      HTI.pt.x := Pt.X;
      HTI.pt.y := Pt.Y;
      sControl.Perform( LVM_SUBITEMHITTEST, 0, Integer( @HTI ) );
      if (HTI.flags <> LVHT_ONITEMSTATEICON) and (HTI.iItem <> -1) then
      begin
        NewLine := HTI.iItem;
        NewCurIdx := HTI.iSubItem;
      end;
      EscCell;
    end;
    WM_LBUTTONDBLCLK:
    begin
      Pt:= TMouseDownPt(Msg.lParam);
      HTI.pt.x := Pt.X;
      HTI.pt.y := Pt.Y;
      sControl.Perform( LVM_SUBITEMHITTEST, 0, Integer( @HTI ) );
      if (HTI.flags <> LVHT_ONITEMSTATEICON) and _prop_DblClick  and (HTI.iItem <> -1) then
      begin
        InitOnEvent;
        _hi_onEvent(_event_onEnterCell);
      end;
    end;
    WM_HSCROLL, WM_VSCROLL:
      EscCell;
    WM_KEYDOWN:
    begin
      Case Msg.WParam of
        VK_LEFT, VK_RIGHT:
        begin
          if (lvoRowSelect in l) then
          begin
            NewCurIdx := NewCurIdx + Msg.wParam - $26;
            if NewCurIdx >= sControl.LVColCount then
              NewCurIdx := sControl.LVColCount - 1
            else
              if NewCurIdx < 0 then NewCurIdx := 0;
            EscCell;
          end;
        end;
        VK_UP, VK_DOWN:
        begin
          NewLine := NewLine + Msg.wParam - $27;
          if NewLine >= sControl.Count then
            NewLine := sControl.Count - 1
          else
            if NewLine < 0 then
              NewLine := 0;
          EscCell;
        end;
        VK_RETURN:
          if _prop_KeyCellEnter = 1 then
          begin
            InitOnEvent;
            _hi_onEvent(_event_onEnterCell);
          end;
        VK_F2:
        begin
          InitOnEvent;
          _hi_onEvent(_event_onEnterCell);
        end;
        VK_ESCAPE:
          EscCell;
      end;
    end;
  end;
  Result := Result or _hi_OnMessage(OldMessage, Msg, Rslt);
end;

procedure THIMST_UseEditCtrl.snewcuridx;
begin
  if not Assigned(_prop_MSTControl) then exit;
  _prop_MSTControl.setnewcuridx(value);
end;

function THIMST_UseEditCtrl.gnewcuridx;
begin
  if Assigned(_prop_MSTControl) then
    Result := _prop_MSTControl.getnewcuridx
  else
    Result := 0;
end;

function THIMST_UseEditCtrl.fredaction;
begin
  if Assigned(_prop_MSTControl) then
    Result := _prop_MSTControl.getfredaction
  else
    Result := true;
end;

function THIMST_UseEditCtrl.fctl3d;
begin
  if Assigned(_prop_MSTControl) then
    Result := _prop_MSTControl.getfctl3d
  else
    Result := true;
end;

procedure THIMST_UseEditCtrl.SetMSTControl;
begin
  if Value = nil then exit;
  FMSTControl := Value;
  sControl := FMSTControl.ctrlpoint;
  FMSTControl.detachwndproc;

  OldMessage:= sControl.OnMessage;
  sControl.OnMessage := _OnMessage;
end;

procedure THIMST_UseEditCtrl._work_doSetData;
var
  dControl: PControl;
begin
  if not Assigned(_prop_MSTControl) then exit;
  dControl := _prop_MSTControl.ctrlpoint;
  dControl.LVItems[NewLine, NewCurIdx] := ToString(_Data);
end;

// Содержит индекс столбца выделенной ячейки
//
procedure THIMST_UseEditCtrl._var_SubItem;
begin
  dtInteger(_Data, NewCurIdx);
end;

// Содержит значение выбранной ячейки под курсором
//
procedure THIMST_UseEditCtrl._var_Cell;
var
  dControl: PControl;
begin
  if not Assigned(_prop_MSTControl) then exit;
  dControl := _prop_MSTControl.ctrlpoint;
  dtString(_Data, dControl.LVItems[NewLine, NewCurIdx]);
end;

// Содержит индекс выделенной строки
//
procedure THIMST_UseEditCtrl._var_Index;
var
  sControl: PControl;
begin
  if not Assigned(_prop_MSTControl) then exit;
  sControl := _prop_MSTControl.ctrlpoint;
  dtInteger(_Data, sControl.CurIndex);
end;

// Матрица строк
//
procedure THIMST_UseEditCtrl._var_Matrix;
begin
  if not Assigned(_prop_MSTControl) then exit;
  _prop_MSTControl.matrix(_Data);
end;

procedure THIMST_UseEditCtrl._work_doClientRect;
var
  Row,Col: integer;
  R, ARect: TRect;
  dTop, dWidth, dHeight, Data: TData;
  b: integer;
  sControl: PControl;
begin
  Row := ReadInteger(_Data, _data_Row);
  Col := ReadInteger(_Data, _data_Col);
  if not Assigned(_prop_MSTControl) then exit;
  sControl := _prop_MSTControl.ctrlpoint;

  R := sControl.LVSubItemRect(Row, Col);
  if Col = 0 then
  begin
    ARect := sControl.LVItemRect(Row, lvipLabel);
    R.Left := ARect.Left;
    R.Right := ARect.Right;
  end;
  if fctl3d then
    b := 2
  else
    b := 1;

  dtInteger(Data, R.Left + sControl.Left + b);
  dtInteger(dWidth, R.Right - R.Left - 1);
  dtInteger(dTop, R.Top + sControl.Top + b);
  dtInteger(dHeight, R.Bottom - R.Top - 1);

  Data.ldata:= @dTop;
  dTop.ldata:= @dWidth;
  dWidth.ldata:= @dHeight;
  _hi_OnEvent_(_event_onClientRect, Data);
end;

end.
